50Gbps Pam4High Speed Self Mating Mezzanine ConnectorPin Spacing: 0.5mmStack Height: 4mmOrientation: Vertical HermaphroditicCompliant: PAM4

PCB Header  Wire to Board ConnectorsCompact design with 2.2 mm high density pitchBuckle design to increase the locking ability of the male and female connectors to avoid product decoupling.The plastic body is designed to reduce deformationBoard fixation screws for secure connection to PCB

The Oupiin 9303-C Series PwrSword® Ultra HD Connector is a versatile, high-current connector ideal for applications demanding efficient power distribution with effective thermal management.High Power & Signal Capabilities: Supports power up to 75A (DC) for high-power applications, 45A (AC) for lower power needs, and signal pin currents up to 1.8A.Configurable Design: The number and placement of power and signal contacts can be tailored to customer specifications.Thermal Efficiency: The low profile (9.60mm above the board) allows improved airflow, enhancing cooling, and is ideal for compact systems like 1U power supplies.Enhanced Contact Stability: Features double spring contacts on signal terminals for reliable connectivity.     Housing & Connection Types: It has ventilated housing, an anti-return pin design, and solder and press-fit options.

  High power capability up to 100A per pin; low power up to 65A per pin, ideal for demanding current requirements  Ultra-low board height of 11.40mm, perfectly suited for 1U/2U power supplies or distribution systems  High-ventilation structure design enhances heat dissipation, ensuring stable system operation  Halogen-free materials meeting international environmental standards  Wide operating temperature range: -40℃ to +125℃, supporting extreme environments  Available in right-angle male and female connectors; straight versions are under development for coplanar and backplane applications  Customizable number and placement of power and signal contacts to meet specific customer needs  Offers both solder and press-fit board mounting options for flexible implementation

Ultra-Slim design, 0.4mm pitch, 0.8mm stack heigh.Stable Contact performance and a better feel for mating.
